Behringer Hygienic Tube Supports are designed to meet the high demands of process piping in hygienic service applications. The automatic slope adjustment feature of the CH Series Dynamic hanger will promote drainability of the piping without imparting unnecessary stress into the piping. Drainability is a critical design feature in hygienic process piping. Behringer Sanitary Pipe and Tube Supports are available in a wide range of sizes and configurations and are offered with both an anchor or guide insert to meet the needs of any application.
The innovative CH Series sanitary tube hangers design was developed with the input of engineers, contractors, end users. The tension ring connection allows the clamp bodies to self adjust, independent of the hanging rod, to the tubes slope. This attribute reduces internal stress on the tube, as well as eliminating an entire step during slope adjustment saving contractors valuable time. The combined use of the CH support and a telescopic stanchion permits line adjustment in the x, y and z axis’s. The ability to make these adjustments, while the sanitary tube hanger is secured to the tubing, eliminates the step of retesting the slope after the hangers have been mounted as a one-piece unit.
Behringer's CH series tube and pipe sanitary hangers are 100% ASME/BPE 2014 compliant while conforming to specification SD-3.1.2.4. This means the CH series sanitary hangers have a rounded geometry and will adjust to accommodate operating conditions such as thermal expansion, thermal cycling, and other distortions while maintaining the required pitch alignment. CH Series Sanitary Tube and Pipe Hanger Specifications Size Range: 0.24 inch diameters through 6.05 inch diameter Hardware: 316 stainless steel, 304 stainless steel Finish: Stainless steel at a 25 RA Plastic: Polysulfone (Black; Anchor and Gray)
